2016 Jeanneau Yachts 64

Boat Overview

An exceptional opportunity to purchase this privately owned and never chartered Jeanneau 64. VAIATA's first owner was an experienced sailor, and the specification was full and well-chosen. Her current owner purchased the boat in 2021 and decided to paint the hull and mast, as well as make significant additions to her inventory including:

• Diving compressor
• Bottle rack
• New RIB and outboard
• New interior upholstery in the saloon

Upon returning from the Caribbean in 2023, a new set of North Sails SRPC sails were delivered and have been hardly used. We believe VAIATA will compare favourably with the remainder of the Jeanneau 64 fleet.

The boat has enjoyed pro-active maintenance by both owners, and service records are available. Viewings are recommended without hesitation. Additional photos available on request.

Notable Features

• Most popular layout: master cabin aft, two double cabins forward, and bunk cabin amidships
• Winged shoal keel with 2.20 metre draft
• Hull, mast, and boom painted in 2021
• All furling rig, fully operable from the cockpit for short-handed sailing
• Captive mainsail winch, electric furlers, and rewind winches for push-button sailing
• New North Sails mainsail, genoa, and staysail in 2023, new gennaker in 2021
• Bow thruster and stern thruster for easy handling in tight spaces
• 60,000 BTU air conditioning throughout
• Large generator and water maker for autonomy when cruising
• Toys: recent tender and outboard, air compressor for diving, and Seabob underwater scooter
• Hydraulic Besenzoni gangway and hydraulically operated back stay and boom vang
• Fully equipped galley and full complement of domestic equipment
• Folding NOMEN cleats and flush deck hatches
• Four underwater lights as well as upward and downward lights on the mast spreaders

Design & Construction

The hull features a hard chine designed to increase performance, speed, stability, and also allows for a more spacious interior. The cockpit occupies over 40% of the deck area. Large windows in the hull allow plenty of light into the interior. Hull painted in 2021. Polyester resins used throughout. Teak laid cockpit, platform, and side decks. GRP arch over cockpit providing support for cockpit canvas and removes main sheet from cockpit area.

Hull

• Vacuum infused with discontinuous, end-grain balsa
• Solid laminate in keel area
• Barrier coat used to guard against osmosis
• Subflooring in saloon area framed with aluminium
• Underwater lights: four blue lights

Appendages

• Winged shoal keel epoxy encapsulated cast iron (2.20 metres)
• Fully balanced spade rudder with a foam core and GRP skin over a stainless steel rudder post
• Steering system uses stainless steel cables driven by sprockets in the steering consoles
• Jefa auto-aligning bearings

Cockpit

• Two composite steering consoles
• Tables and seating area to port and starboard separated from the sailing area aft
• Teak laid cockpit
• Kenyon fold away electric grill in aft deck locker
• Fridge
• Sink
• Port side table on electric pedestal with infill cushion to create a large sun bed
• Tables are varnished
• Extra grabrails on the helm pedestals
• Extra dimmable LED lights in the cockpit, side decks, and garage door
• Extra pad eyes installed

Interior & Accommodation

Unique skipper lounge in saloon to port with arm chairs custom fitted in 2023. Contemporary Winch Design interior finish with Alpi White Oak furniture and Dark Oak floor. 60,000 BTU multi-zone air conditioning throughout including skipper cabin. Interior upholstery in saloon renewed in 2021 grey fabric. LED interior lighting and dimmer switches for overhead and indirect lighting in saloon and cabins. Day bathroom in corridor between galley and master cabin. Electric flush fresh water toilets throughout except in skipper cabin which is manual. Electrically operated pleated blinds for saloon with remote control. Curtains for all hull windows new in 2021.

Saloon

• Seating area to starboard with folding luxury table on electric pedestal
• Saloon table modified to be able to slide chairs underneath
• Bar area to port
• Unique skippers lounge to port custom made for the current owner in 2023 with two arm chairs and storage

Galley & Domestic

• Miele convection microwave oven
• Electric induction stove with ceramic burners
• One fridge in bar area in the saloon
• Fridge and two freezer drawers in galley
• Wine cooler in galley
• Miele dishwasher
• Washing machine with combined dryer
• Extractor fan
• Soft closing drawers

Full Beam Master Cabin Aft

• Island double bed (205 x 180cm)
• Large double hanging locker with interior courtesy lighting and six storage drawers in lower unit
• Vanity desk to port with swing out stool and sofa to starboard
• Night stands on each side of the bed with storage drawers and upper bookshelves
• Two fixed hull ports
• Two large curved opening ports into cockpit for ventilation and evacuation with pleated shades and insect screens
• Large en-suite bathroom

VIP Guest Cabins Forward Symmetrical to Port and Starboard

• Double berth
• Hanging locker
• LED reading lights
• Indirect lighting
• Two large storage lockers
• Each with access to en-suite bathroom

Lateral Guest Cabin

• Two single upper and lower bunks
• Large fixed hull port
• Opening hatch
• Large hanging and storage lockers
• Forward access door to engine room

Crew Cabin

• Access through deck or through hatch in starboard forward bathroom
• Fitted with two bunks

Propulsion

VOLVO D4-180 HP

• Common rail fuel injection
• Hydraulic gearbox, rate 2:48
• 24V 110A alternator
• 12V 115A alternator
• EVC panel and 4 display
• Keyless ignition system
• Engine room camera with infrared (displays on chart plotters)

Sound insulation: GRP engine bed and liner. Dripless shaft gland with water lubrication. Stainless steel 40mm shaft with bronze P-bracket. Rope cutter on shaft. 4-blade Flex-o-Fold folding propeller.

Exhaust

• Stainless steel exhaust mixer
• Stainless steel exhaust fitting on hull

Ventilation

• Extractor fans located in engine room for maximum sound reduction
• Ventilation ducting vents exit in coaming

Fuel

• Primary tank: stainless steel 500 litre tank under main saloon
• Secondary tank: roto moulded 325 litre tank with transfer pump to primary tank
• Inline fuel/water separator with electronic sensor for water
• Fuel gauge at electrical panel

Bow Thruster

• 24V with 240kg of thrust
• Mounted in 250mm flared tunnel moulded into the hull to reduce drag
• Dedicated battery bank

Stern Thruster

• Retractable
• 24V with 240kg of thrust
• Dedicated battery bank

Electrical System

12 / 24 / 220V electrical system.

Generator: ONAN 17.5kW in lieu of standard.

Inverter: Mastervolt 2000W.

Alternators

• 24V 110A alternator
• 12V 115A alternator

Charging

• 24V 100A charger
• 24V 100A charger
• 12V 25A charger

Batteries

• 420Ah domestic battery bank new in 2021
• Engine start battery
• Generator start battery
• Dedicated bow thruster battery bank
• Dedicated stern thruster battery bank

Digital 3.5 display that shows and controls AC voltage and source selection, battery monitoring, tank monitoring, and fuel transfer system. Dedicated electrical closet accessible in port, aft passage centralizes electrical functions including 24V breaker panel for high-load equipment. 220V shore power socket with cable. EU 220V sockets and USB sockets throughout.

Water System

Fresh Water

• Watermaker: Sea Recovery Aqua Whisper AM750 120 litres/hour
• High-pressure twin 24V pumps, inline filter, and accumulator tank
• Three water tanks: 2 x 400 litres and 1 x 200 litres
• Tank manifold with selector valves located under saloon floor
• Fresh water foot pump in galley
• 80 litre hot water heater connected to engine heat exchanger and 220V electrical system
• Shore water connection in cockpit with water pressure regulator
• Water connection point and hose reel for wash down in anchor locker
• Extra water connection point for wash down installed in garage
• Shower in garage adjacent to swim platform

Black & Grey Water

• Four 88 litre holding tanks located under floor in forward and aft section with overboard macerator pump
• All black water macerator pumps new in 2023
• Collector system at each head compartment centralizes sink and shower grey water for overboard discharge
• This reduces the number of through hull fittings

Bilge Pumps

• Electric bilge pump located in bilge sump area with activation via switch at electrical panel
• Dual-action manual bilge pump located in cockpit
• Electric bilge pump located in forward sail locker

Rig & Deck Gear

Fractional rigged sloop. Keel stepped aluminium in-mast furling mast by Sparcraft painted black in 2021. Triple swept back spreaders. Boom painted black in 2021. Below deck captive winch for mainsheet. Fixed inner forestay with electric furler. Genoa on electric furler. Hydraulic adjustable backstay. Hydraulic adjustable boom vang. Rigging for Code 0. Upward and downward spreader lights.

• Two electric ST70 primary winches
• Two electric ST60 rewind secondary winches
• Genoa tracks on side deck for overlapping genoa
• Spinnaker deck fittings
• Fittings and control lines for whisker pole
• Double control buttons at the consoles for the rewind winches
• Additional mast-mounted winch for tensioning halyards
• Halyard tensioner tracks for halyards of the furling sails

Sails

• North Sails SRPC furling mainsail (2023)
• North Sails SRPC furling genoa (2023)
• North Sails SRPC furling staysail (2023)
• Incidence gennaker (2021)
• North Sails Code 0

Navigation

Raymarine instrumentation package:

• i70 display
• Tri data
• Wind indicator

Raymarine autopilot with hydraulic ram. Raymarine multifunction GS125 touch screen at each helm. Additional Raymarine multifunction display in saloon. Raymarine 260 VHF with dual station and AIS receiver. AIS transponder. Fog horn and hailer. Raymarine 4kW HD digital radar. Satellite phone.

Ground Tackle & Mooring

Retractable Besenzoni hydraulic gangway. Folding side ladders for ease of boarding when side-to. 3000W 24V electric windlass with capstan to aid mooring. Stainless steel anchor. 100m 14mm chain. Chain counter and windlass control at helm. Electric washdown pump in the anchor locker (fresh and salt water). Roll up hose in anchor locker. Eight NOMEN folding cleats. Fairleads on transom. Fenders and mooring lines.

Covers & Cushions

• Sprayhood in Cadet Grey Sunbrella fabric with windscreen function and LED lighting
• Fold-away bimini in Cadet Grey Sunbrella fabric
• Bridge piece from sprayhood to bimini in Cadet Grey Sunbrella fabric
• Covers for helm stations and winches
• Protective cover in Sunbrella fabric for the cockpit tables
• Cockpit cushions with backrests
• Cockpit cushion insert for port-side table
• Aft sundeck mattresses

Tender & Toys

• Highfield CL 310 2022
• Suzuki 20 HP outboard with electric start new in 2022
• Removable cradle on foredeck for tender
• Air compressor for diving 2021
• Rack for four tanks in garage
• Two complete dive sets with CBD, fins, and dive computer
• Seabob underwater scooter with custom cradle in the garage
• Electric air pump for inflating tender or toys located in the garage

Entertainment

• Fusion AV750 DVD/CD/MP3 player one in saloon and one in master cabin
• BOSE Acoustimass 3 speakers in saloon
• BOSE 131 speakers in master cabin
• Cockpit speakers
• TV antenna for masthead
• TV in saloon
• TV in master cabin
• Media hard drive with wireless connection

Safety

• Self-draining cockpit
• 13 escape hatches throughout the interior
• Automatic engine room fire-extinguishing system with release handles under galley steps
• Emergency tiller
• Folding pad eyes
• Bilge pumps
• Emergency ladder

Please note that equipment such as life rafts, EPIRBs, fire extinguishers, and flares require regular servicing and/or renewal. If such equipment is left on-board as part of the sale, the buyer should ensure the equipment is suited to their usage plans, assume service or replacement will be required by them after purchase, and complies with any flagging requirements.
