2020 Azimut Grande 27 Metri

KEY FEATURES

• Excellent condition
• Five-cabin layout
• Best interior volume of her class
• Advanced options and upgrades
• Registered below 24 meters
• Low engine hours
• Bright and modern Salvagni interior design
• Full beam master cabin
• Large flybridge
• Beach-club style aft platform
• New Jacuzzi Fitted
• Commercially Compliant

OTHER MACHINERY

Electricity:

• 230 V - 50 Hz AC
• 24 V DC from battery set
• 12 V DC from battery set and AC/DC voltage reducer
• Shore-powered power supply
• DC electric panel: Installed on fore bulkhead of the engine room
• AC electric panel: Installed on fore bulkhead of the engine room
• Auxiliary electric panel: Installed in the wheelhouse
• Emergency control panel: Installed in the wheelhouse
• Battery cut-out/emergency/fire extinguishing system control panel: located in the cockpit
• Dimmable lights in the interior, cockpit and flybridge (option)

Shore power:

• EU 2 sockets, 3P 63A
• USA 2 sockets, 4P 100A and 4P 50A
• The AC power sources terminate on the main electric panel in the engine room, provided with a voltmeter and ammeter for the 230 V power supply. The AC power sources are protected by suitably sized fuses, and introduced into the network by means of remote control switches
• 2x electrical shore power cable entry (option)

Batteries:

• Services: 12x 10.90 Ah@12 V
• Engines: 6x 6.90 Ah@12 V
• Generator: 2x 2.90 Ah@12 V
• Service battery charger / service backup: 2x Mastervolt 80 Ah - 24 V
• Engine start-up battery charger: 1x Mastervolt 30 Ah - 24 V
• Genset start-up battery charger: 1x Mastervolt 10 Ah - 12 V

Air Conditioning:

• Air conditioning type: The system is of the thermally-treated water circulation type, with fancoils located in various rooms
• Compressor unit in engine room, total 180,000 BTU with inverter technology
• One seawater pump

Distribution:

• Wheelhouse: three fancoils of which two AP5 (9,200 BTU) and one AP10 (16,000 BTU)
• Owner’s cabin: two fancoils AP8 (12.500 BTU)
• Owner's head: one fancoil AP3 (6.200 BTU)
• Galley: one fancoil AP8 (12.500 BTU)
• Dining: two fancoils AP8 (12.500 BTU)
• Saloon: two fancoils AP8 (12.500 BTU)
• VIP cabin: two fancoils AP5 (9.200 BTU)
• Port guest cabin: one fancoil AP5 (9.200 BTU)
• Starboard guest cabin: one fancoil AP5 (9.200 BTU)
• Commander's cabin: one fancoil AP1 (4.480 BTU)
• Crew cabin and crew dinette: one fancoil AP3 (6.200 BTU)
• Each area has its own control panel making it independent
• Underwater lighting at the stern - oceanLed Explore (4x) (option)
• Underwater lighting lateral - oceanLed Explore (2x each side, total 4) (option)
• Watermaker 180L hour HP (option)

ACCOMMODATION

Owner’s cabin:

• Double bed at the center of the yacht, with foldaway bed base and locker Access to service compartment under the bed
• Walk-in wardrobe with wardrobes equipped with hanger bar, internal lighting, chest of drawers, full-height mirror with concealed sliding door
• Two bedside tables with drawer
• Fix side windows on each side of the cabin, full height
• Chest of drawers, forward of the owner's bed
• Main lighting with dimmer, LED technology
• LED technology courtesy lighting
• Full-length mirror
• Venetian blinds
• Wood-upholstered bulwarks
• Lacquered and wood ceiling
• Carpeted floor
• Air conditioning system control panel

Two double cabins:

• Double bed with foldaway bed plane and locker below, headboard
• Two bedside tables
• Wardrobe on port side with hanger bar and internal lighting
• Chest of drawers
• Two wall units with storage above side panoramic windows
• Lighting with recessed LED spotlights
• Two LED wall lights on headboard
• Fixed panoramic windows
• Openable round portlights built-in the panoramic windows
• Wooden Venetian blinds
• Lacquered and wood ceiling
• Wooden/fabric upholstered bulwarks
• Lacquered/fabric-upholstered headlining
• Carpeted floor
• LED courtesy lights
• Air conditioning system control panel

Two twin guest cabins:

• Double bed placed transversally on bulwark, with foldaway bed plane and locker below, headboard
• Two bedside tables with drawer
• One wardrobe with a hanger bar and shelves
• Lacquered ceiling
• Upholstery on bulwark in wood essence
• Full-length mirror
• Panoramic fixed window with built-in portlight
• Venetian blind
• Carpeted floor
• LED technology lighting
• Headboard light
• Air conditioning system control panel

Custom options:

• Flybridge U-bench extension, curved furniture
• Stainless Steel Teak Bar Stool on flybridge 3 pieces
• Teak table on bow
• Mosquito nets for portholes
• Salon round table
• Wooden floor in salon/couch area
• Lacquer table
• Marble washbasins, shower cubicle floor and wall and kitchen exchange
• Reading lights flexible installation in owner's cabin
• Glass top fixed on dining table in salon

GALLEY & LAUNDRY EQUIPMENT

Galley

• Located on port side, the access is through concealed sliding door located forward of the pantry. This layout allows full isolation of this area from the saloon and dining area reserved for the owner and his guests.
• 419 l (14.8 cu.ft) refrigerator + 247 l (8.7 cu.ft) freezer
• Dishwasher
• Stainless steel sink with faucets Extractor hood
• 76 l (2.68 cu.ft) oven Four-burner induction range
• Flooring in vinyl
• Composite material worktop
• Storage wall units on port bulwark
• LED technology spotlights
• Sockets
• Air conditioning outlet grating
• Wine cooler in galley (option)

Laundry:

• Washer-dryer in crew cabin (option)

Exterior appliances:

• Icemaker flybridge (option)
• Refrigerator in cockpit furniture (option)

COMMUNICATION EQUIPMENT

• Communication systems (VHF)
• Professional Wifi system (option)
• Pre-insertion for SAT antenna KVH TV6/TV8

NAVIGATION EQUIPMENT

Simrad gold package:
Roll bar:

• RADAR HALO3 VHF ANTENNAS (x2)
• GPS ANTENNAS - GS 25

Flybridge:

• Display multifunction NSS-16 EVO 3 (x2) VHF Station RS90
• Remote controller OP50

Wheelhouse:

• Display multifunction NSS-16 EVO 3 (x3) VHF Station RS90
• Remote controller OP50 Radar interface module
• VHF transreceiver RS90 (with integrated AIS receiver)
• Autopilot computer for optimus SG05
• Compass precision-9 Multisensor DST800

Other:

• Panasonic video cameras (x4) Electric searchlight
• Bow spotlight Stern spotlight on spoiler from flybridge

ENTERTAINMENT EQUIPMENT

Audio/Video Gold Package
Guests cabins:

• Smart TV LED LG 43" 50/60 Hz
• Amplifier FUSION APOLLO
• Speakers FUSION 6“ – 2 WAY FULL RANGE
• USB & 3.5 mm AUX CONNECTOR
• AUDIOVIDEO GOLD PACKAGE
• SMART TV LED LG 32" 50/60 Hz
• APPLE TV 4 HD 32GB

Salon:

• Speakers BOSE LIFESTYLE 600
• Smart TV LED LG 55" 4K 50/60 Hz
• Subwoofer BOSE LIFESTYLE 600
• APPLE TV 4 HD 32GB
• SONOS CONNECT AMP

Master cabin:

• Subwoofer BOSE LIFESTYLE 550
• Speakers BOSE LIFESTYLE 550
• Smart TV LED LG 55" 4K 50/60 Hz
• APPLE TV 4 HD 32GB

Aft cockpit:

• Speakers JL 7.7” MX-770

Flybridge and bow area:

• Speakers JL 7.7” MX-770
• Subwoofer JL 10“ M6-10IB-S

TENDERS & TOYS

• Tender is not included in the sale, below the possible option:
• MAXIMUM DIMENSIONS OF TENDER - GARAGE: 4.50 x 2.00 m (14' 9'' x 6' 6.7'')
• RECOMMENDED TENDER - GARAGE: WILLIAMS DJ445

DECK EQUIPMENT

Anchor

• Two anchors 135kg

Anchor chain

• Quantity: 2
• Diameter 12 mm (0.47 in)
• Length (each) 130 m (328’ 1”)
• Material: galvanized steel

Hawse plate

• Quantity: 2
• Thickness 3 mm (0.12 in)
• Material: stainless steel

Anchor winch

• Quantity: 2
• Engine power 4000 W
• Engine voltage 230 V - 50/60Hz threephase

Mooring winch

• Quantity: 2
• Engine power 3600 W
• Engine voltage 230 V - 50/60Hz threephase

Chocks

• Quantity - bow: 4 Quantity - stern: two (with rollers)
• Material: stainless steel

Cleats

• Quantity - bow: 4 (mushroom type) Quantity - midship: 2
• Quantity - stern, on mooring station: 2 Material: stainless steel

Options

• Deck washing system at bow, on fly and at stern
• Fixed fresh water connection
• Cockpit cover sunshade electric Preparation for electric awning flybridge to stern
• Preparation (power) for additional BBQ furniture Flybridge to stern
• Preparation for recording bow bimini with carbon poles and sail

SAFETY & SECURITY EQUIPMENT

Fire extinguishing system

• System manual activation control in the cockpit
• System indicators/reset on internal and flybridge dashboards and also in the crew room
• One 106-liter (3.74 cu.ft) gas extinguisher in the engine room with nozzles located above the engines
• Two hoses located in the compartment under the cockpit's ladder and in the chain locker at the bow
• All safety equipment requested by current commercial regulation.

REFIT HISTORY

• All maintenance/services performed in line with highest standards.
• Year-round crew on board.

Upgrades performed in 2022/2023/2024:

• Two anchors 135kg
• Additional 30 meters of anchor chains Installed 5G Router + Antenna Peplink 4 + Starlink membranes on the Idromar
• Induction hob 90cm (60cm as standard) Additional fridge in the lobby
• Second grill at the flybridge
• Diesel pump in the garage for tender
• Shower refit
• Hard-top/coaming/coach roof Wrap in Black
• Jacuzzi and Sun-pads installed on aft of Flybridge
• Timothy Oulton, London Saloon/Dining Furniture
