2013 Princess 56

Boat Overview

The Princess 56 is a compact yacht measuring less than 60 feet. It features an open flybridge with two J-shaped seating areas: one around a table for dining and another near the upper helm station. The aft main deck has a dinette that leads into a spacious interior salon with large windows. A second dinette on the portside faces an open galley, separated from the helm station by a low divider. A central staircase provides access to three cabins: a full-beam master suite amidships, a double-berth VIP cabin in the bow, and a twin cabin in between. Additionally, there is a crew cabin located aft of the engine room. The bathing platform can be equipped with an optional mechanism for raising and lowering it into the water for easier tender operations. The standard twin CAT C12A engines allow the Princess 56 to reach top speeds of 29 knots.

Manufacturer Provided Description

From the moment you step aboard her teak decking, luxurious space is a constant companion. The vast flybridge enjoys a convertible sunbed, twin helm seats, a wetbar, barbecue, and ergonomic dining areas. This oasis of calm can then be propelled up to a top speed of 34 knots, and all with nimble composure. Magnificent refinement and performance in equal measure.

The main deck helm position provides exceptionally comfortable cruising. The well-equipped galley is located just aft of the helm with a sociable dining area adjacent. Below deck, full-standing headroom adds to the spacious ambience throughout the three cabins and full beam master stateroom, affording your guests with the luxury of space for their time on board.

Deck

• Teak-laid transom platform, cockpit deck, flybridge stairway and stairs to side decks
• Reversible electric anchor winch with foredeck, main helm and flybridge controls
• Self stowing 25kg/55lb Delta anchor with 40m of chain
• Stemhead roller with automatic anchor launch and retrieve
• Stainless-steel bow, stern and spring cleats
• Stainless-steel bow fairleads
• Stainless-steel pulpit and guard rails
• Stainless-steel coachroof and flybridge rails
• PVC rubbing band with stainless-steel insert
• Foredeck hatch
• Full set of IMCO navigation lights
• Riding light
• Twin beam searchlight with dual-station remote controls
• Twin electric horns
• Fuel and water fillers

Cockpit

• Self-draining
• U-shaped seating with teak table
• Lockable access hatch to engine room and lazarette
• Steps to side decks
• Cockpit lighting
• Transom gate leading to bathing platform
• Side lockers
• Fender storage
• 220/240v shore support inlet
• Stainless-steel handrails
• Locker containing remote fuel cocks, manual bilge pump with valve chest and manual controls for automatic fire extinguishers
• Integral stairway to flybridge with teak treads
• Teak-laid transom bathing platform with foldaway swimming ladder, hot and cold shower
• Dinghy chock system
• Electro-hydraulic raise/lower mechanism for transom platform (suitable for a tender up to 400kgs) is optionally available

Accommodations

Deck Saloon

• Triple stainless-steel framed sliding doors to cockpit
• U-shaped sofa with coffee table
• Two-seater sofa to port
• 46” LED TV with electric raise/lower mechanism
• Sideboard units with refrigerator, bottle and glass storage and radio/MP3
• Dining area with U-shaped seating and 2 additional stools (to seat 6 in total)

OWNER’S STATEROOM

• Large double bed with drawers below
• Wardrobe with shelves
• Dressing table
• Sofa
• Stereo radio, MP3
• Overhead and individual berth lights
• En suite bathroom

FORWARD GUEST CABIN

• Large double bed with drawers below
• Wardrobe with shelves
• Vanity unit
• Storage lockers and drawers
• Overhead and individual berth lights
• Deck hatch with fly screen and blind
• En suite bathroom with day access

STARBOARD GUEST CABIN

• Two full-size single beds
• Wardrobe with shelf
• Storage lockers
• Overhead and individual berth lights

OPTIONAL AFT CABIN

• Single berth
• Storage space
• Overhead and individual berth lights
• Electric quietflush toilet and washbasin

Galley

• 3-zone ceramic hob
• Hob extractor
• Combination microwave/conventional oven with grill
• Stainless-steel sink with monobloc mixer tap
• Refrigerator with freezer compartment
• Waste bin
• Chopping board
• Provision for dishwasher and additional refrigerator

Power and Drive Systems

• 4-bladed propellers in nickel aluminium bronze
• Bow thruster (130kgf/287lbf)
• Power-assisted electro-hydraulic steering system with hydraulic back-up
• Electronic engine and gear shift controls
• Dripless shaft seals
• Engine room extractor fan with electronic time delay

Electrical

24 Volt

• 4 x heavy duty batteries for engine starting
• 4 x heavy duty auxiliary batteries
• 60 amp battery charger charges both banks of batteries via an automatic switch charging system
• Remote battery master switches with control switch at main panel
• LED lighting throughout

220/240 Volt

• 9.5kW diesel generator in own sound shield with water cooled specially silenced exhaust
• Polarity check system
• Earth leakage safety trip
• Power points in all areas

Flybridge

• Dual station instrumentation, controls and alarm system including VHF/RT, speed and distance log, echo sounder with alarm and autopilot
• Large seating area with teak table
• L-shaped seat (converts to sunbed)
• Loudspeakers linked to saloon stereo
• Wetbar including sink with electric barbecue, and refrigerated coolbox

Lower Helm Position

• Twin helm seats with fore and aft adjustment for helmsman
• Electric opening windows at helm position and port side
• Full engine instrumentation including fuel gauges, exhaust temperature and engine warning system and rudder position indicator
• Navigation system including VHF/RT, speed and distance log, echo sounder with alarm, autopilot and high speed magnetic compass
• Controls for bow thruster, windscreen wipers, bilge pump and trim tabs (with indicator)
• Chart table with light and chart stowage
• 12v outlet
• Red night lighting
• 24v and 220/240v electrical control panels

Engine Notes

2 x 715mhp Speed range: 29-30 Knots

Details

Engines & Drive

• Caterpillar C12 A (2x 715 mhp)

Stabilisation

• Seakeeper Gyro Stabiliser (M8000)

Hull Colour

• Midnight Blue to 1” above boot topping line (with dark blue water line & dark blue antifouling, hull fendering is white with stainless steel insert & bathing platform fendering is black with stainless steel insert)

Interior Furniture

• Serotina Cherry interior wood SATIN finish (Teak galley floor as standard)

Layout

• Supply and fit P60 rectangular coffee table in place of standard

Galley

• Fit EMPERADOR DARK marble galley worktop

Bathroom

• Fit COCOA BROWN avonite to bathroom worktops in place of standard

• Fit EMPERADOR MARBLE to Master Stateroom bathroom worktop in place of standard

Deck Hardware

• Electro-hydraulic swimming platform (400Kg SWL)

• Additional 20m of 10mm anchor chain to give a total of 60 meters

• Teak laid flybridge deck

Color Scheme

• Carpet: Loop Ivory

• Upholstery: PARCHMENT LEATHER

• Saloon Patio Curtain: Lautner Graphite

• Bedheads: Discotheque Graphite

• Fitted Bedcovers: Extra Easy Col 18

• Additional charge for Quartz Leather upholstery in deck saloon

Generator

• ONAN 17.5kW generator in place of standard (recommended when gyro stabilisers & aircon are specified)

Electrical

• UK 220v/240v sockets

• Foredeck freshwater anchor / deckwash system

• Icemaker (fitted in saloon)

• Underwater transom lights (2 Blue A12 PRO LED)

Audio Visual & Communications

• PREMIUM AUDIO SYSTEM – Incorporates:

• Saloon – BOSE 3.2.1 GS DVD media system linked to TV

• Master Stateroom – BOSE 3.2.1 GS DBD media system (inked to optional TV when ordered)

• Flybridge – Waterproof Radio/iPOD/MP3 player with waterproof speakers

• 32” LED TV in Master Stateroom (Only applicable when the Premium Audio System is selected

• iPOD docking station in Saloon

• iPOD docking station in Master Stateroom & Forward Cabin (in addition to Saloon already specified)

Navigation

• Raymarine e125 Chartplotter/GPS with externa GPS and 12.1” brilliant colour multifunction display at lower helm

• Raymarine SHD digital colour radar with 48”, 4Kw scanner (only if chartplotter is specified)

• Raymarine e 125 multifunction 121” brillian colour display at upper helm

• Rest of World version plotter charts

• Fit INTERNATIONAL VHF

Airconditioning

• Reverse Cycle Airconditioning/Heating: 68,000 BTU Suitable for ambient temperature to 35°C (e.g. Florida/Eastern Mediterranean)

• Condensing unit 40,000 BTU supplying outlets in Saloon, Dinette, Helm & Galley areas (with SMX controls)

• Condensing unit 10,000 BTU supplying 10,000 BTU outlet in Forward Cabin (with SMX control)

• Condensing unit 10,000 BTU supplying 10,000 BTU outlet in Stateroom (with SMX control)

• Condensing unit 8,000 BTU supplying 8,000 BTU outlet in Starboard Cabin (with SMX control)

• This also includes outlets in bathrooms.

• Recommended generator: 13.5kW

Holding Tank / Toilets

• System 2: (Non Aft Cabin)

• Toilet discharging into the holding tank but also having the ability to discharge directly overboard via a Y valve fitted in the discharge lines. The holding tank has electric overboard discharge as well as reserve manual pump out and dockside discharge arrangements.

Exterior Upholstery / Canvas/ Covers

• Foredeck sunbed cushions in Movida BEIGE with MET METEOR trim & contrast stitching

• Cockpit & flybridge seating including helm seats and sunbed cushions – Movida BEIGE with MET METEOR inlay & contrasting stitching

• Bimini Top – Dark Blue sunbrella canvas

• Additional charge for electro-hydraulic powered bimini top
